MCCAULEY MS18 Subwoofer

McCauley MS18 includes integrated mounting components and can be paired with M210 speakers for flexible setups such as ground stacking or flying. The enclosure is made of multi-ply composite wood with a rugged polyurea finish, and the front is protected by a sturdy metal grille

Weight
64kg
Box Size
700mm x 728mm x 606mm
Colour
Cabinet Color:Black;Grille Color:Black fabric
Frequency Response
37Hz-250Hz
Unit Configuration
Low-frequency unit: 1X18"/ 4"(100mm);1x12"/ 3"(75mm)
Download Specification Sheet
Details Specification Parameters

McCauley MS18 includes integrated mounting components and can be paired with M210 speakers for flexible setups such as ground stacking or flying. The enclosure is made of multi-ply composite wood with a rugged polyurea finish, and the front is protected by a sturdy metal grille



Applications:

Bar sound reinforcement, concerts, theaters, indoor and outdoor performances, fixed installation in indoor auditoriums, stadiums, and other venues.


Rated/Peak Power:800/3200W

Sensitivity(1w/1m):97dB

Frequency Response(-5dB ) 37Hz-250Hz

Norminal Impedance: 8 0hm

Low-frequency unit: 1X18"/ 4"(100mm);1x12"/ 3"(75mm)

Maximum Sound Pressure Level:128/137dB;

Coupling Angle Settings: 0° and 2.5°

Dimensions (W x D x H): 700mm x 728mm x 606mm

Cabinet Color:Black;Grille Color:Black fabric

Weight: 64kg

Wiring Type  2*NL8MP
