Product Features

- Analog Input Channels: 8

- Analog Output Channels: 8

- Dante Input Channels: 8

- Dante Output Channels: 8

- Processor: ADI SHARC 21489 @ 450 MHz SIMD

- DSP Processing Power: 400 MIPS, 1.6 GFLOPS

- Sampling Rate: 48 kHz, ±100 ppm

Functional Highlights

- Configurable processing modules, freely replaceable based on requirements

- Supports simultaneous online operation of up to 8 devices

- Built-in 1-in / 1-out USB sound card, supporting music playback, recording, and soft video conferencing such as Zoom, Tencent Meeting, DingTalk Meeting, etc.

- Bus-based AEC (Acoustic Echo Cancellation), tail length: 512ms, convergence rate: 60dB/s, echo cancellation depth: 60dB

- Independent channel AFC (Acoustic Feedback Cancellation), notch filter algorithm, gain before feedback improvement: 10dB

- ANS (Automatic Noise Suppression), SNR improvement of 18dB

- Ducker

- ANC (Automatic Noise Compensation)

- Gain Sharing Automatic Mixing (AMC), Gate Mixer

- 12-band British Parametric EQ, with 5 filter types available: Parametric, Low Shelf, High Shelf, Lowpass, Highpass

- Customizable end-user interface, supporting management of up to 30 devices on a single interface

- Camera tracking support

- 8-channel GPIO

- Central control function, supporting RS232, RS485, and UDP control protocols, enabling integrated control of power, signal switching, environment,

audio, and more, achieving one-touch system activation
