McCauley(美嘉声)AC15 is a high-quality two-way full-range loudspeaker. With a compact enclosure and high sound pressure output, it can deliver excellent sound quality and good vocal clarity even when producing peak sound pressure levels of up to 128 dB at 1 meter.

This compact unit features a 15" (75mm) woofer, a 2.75" (66mm) tweeter, and a 500-watt power handling capacity, delivering surprisingly powerful and impactful audio performance. The AC15 can be used either vertically or horizontally. Its directional coverage of 80° x 50° allows the high-frequency horn to adapt to the speaker's placement, ensuring even and controlled high-frequency dispersion.

When mounted near a wall or ceiling, the optimized, compact, trapezoidal enclosure with a bass reflex port is capable of producing impressive low-frequency response without the need for an additional subwoofer. The AC15's trapezoidal cabinet is constructed from 15mm multi-layer composite plywood and is equipped with M8 threaded inserts for rigging and installation purposes.

Product Features

Passive two-way system speaker Suitable for main sound reinforcement and stage monitoring applications

Selectable vertical or horizontal placement Selectable vertical or horizontal placement Perforated steel grille with protective foam mesh

Trapezoidal enclosure with textured finish

 8Ω nominal impedance

 Dual NL4 connectors

Multiple M8 rigging points for suspension

Applications

For advanced karaoke rooms, lounge bars with sub-bass playback requirements

Multi-purpose halls, high-end hotel clubs

Portable live sound applications, band sound reinforcement

High-Frequency Driver: 1 .4"/ 2.5"(65mm)

Low-Frequency Driver:15"/ 3"( 75mm)

Frequency Respons:   45Hz-18KHz

Sensitivity:  99dB

Maximum Sound Pressure Level (SPL):   134dB

Impedance:    8Ω

Rated Power:   500W   (AES)

Peak Power:   2000W (PEAK)

Dispersion Angle: 80°（W ）×50°(H)

Finish: Matte Black Paint

Dimensions: 430mm(W)×690mm(H)415mm(D)

 Weight:   36kg
