AC1001 10-inch rear-vented full-range loudspeaker

McCauley AC1001 Full-Range Passive Two-Way Loudspeaker is specifically designed for high-end entertainment applications, delivering optimal near-field sound quality and tonal coherence, while maintaining stable sound pressure levels even at high volumes. It features a 10-inch woofer and a precision neodymium magnet compression driver with a 1.7" (44mm) diaphragm for clear, detailed high-frequency reproduction. The bass reflex port is precisely tuned and located on the rear panel of the speaker, which effectively enhances low-frequency performance when the speaker is mounted in front of a wall. The AC1001 is ideal for use in high-end KTV rooms, karaoke lounges, upscale private clubs, custom home theaters, and entertainment clubs。

Weight

16kg

Box Size

310mm(W)×500mm(H)346mm(D)

Colour

Matte Black Paint

Frequency Response

62Hz-18KHz

Unit Configuration

High-Frequency Driver：1 "/ 1.7"(44mm)
Low-Frequency Driver：10"/2.5"(65mm)

Download Specification Sheet

Details Specification Parameters

The bass reflex port is precisely tuned and located on the rear panel of the speaker, which effectively enhances low-frequency performance when the speaker is mounted in front of a wall.

The AC1001 is ideal for use in high-end KTV rooms, karaoke lounges, upscale private clubs, custom home theaters, and entertainment clubs。

Applications

live sound in bars, concert halls, theaters, outdoor/indoor events, permanent installations in auditoriums, sports stadiums, and more

High-Frequency Driver: 1" / 1.7" (44mm)

Low-Frequency Driver: 10" / 2.5" (65mm)

Frequency Response: 62Hz – 18kHz

Sensitivity: 97dB

Maximum Sound Pressure Level (SPL): 128dB

Impedance: 8Ω

Rated Power (AES): 350W

Peak Power (PEAK): 1400W

Dispersion Angle: 90° (W) × 70° (H)

Finish: Matte Black Paint

Cabinet Dimensions (W × H × D): 310mm × 500mm × 346mm

Weight:16kg
