McCauley AC1201 Full-Range Passive Two-Way Loudspeaker is specifically designed for high-end entertainment applications, delivering optimal near-field sound quality and tonal coherence, while maintaining stable sound pressure levels even at high volumes. It features a 10-inch woofer and a precision neodymium magnet compression driver with a 1.75" (44mm) diaphragm for clear, detailed high-frequency reproduction.

The bass reflex port is precisely tuned and located on the rear panel of the speaker, which effectively enhances low-frequency performance when the speaker is mounted in front of a wall.

The AC1201 is ideal for use in high-end KTV rooms, karaoke lounges, upscale private clubs, custom home theaters, and entertainment clubs。

Applications

live sound in bars, concert halls, theaters, outdoor/indoor events, permanent installations in auditoriums, sports stadiums, and more

High-Frequency Driver:1 "/ 1.7"(44mm)

Low-Frequency Driver:12"/ 3"( 75mm)

Frequency Respons:  56Hz-18KHz

Sensitivity:  98dB

Maximum Sound Pressure Level (SPL):  130dB

Impedance:   8Ω

Rated Power (AES): 500W   (AES)

Peak Power (PEAK): 2000W (PEAK)

Dispersion Angle: 90°（W ）×70°(H)

Finish: Matte Black Paint

Cabinet Dimensions: 363mm(W)×600mm(H)406mm(D)

Weight :  16kg
